Enhance the performance and accuracy of your measurement systems with our wide range of high-quality accessories. From calibration tools to mounting solutions, our accessories are designed to optimize the functionality of your equipment, ensuring precise and reliable results. Explore our selection to find the perfect add-ons to support your measurement needs and improve workflow efficiency.
%
Customer Satisfaction
+
Years of Expertise
X
Durability
Our Accessories Portfolio
Tilt and Center Worktables
Facilitate precise positioning and leveling of parts during measurement.
Custom Frame Heights (Low Profile Shown)
Tailored for specific needs, with a low-profile option for better accessibility and stability.
Vacuum Controllers
Run on shop air with vacuum release buttons, adjustable settings, and pressure/vacuum gauges.
Small & Large Custom Jigs
Collet Chucks
Scroll Chuck with 3-Point contact
- Forged steel body ensures high-speed lathe performance
- Precision-balanced, hardened scroll for durability and accuracy
- American standard tongue & groove jaws for versatile top tooling options
Micro Test Ball Sets
Master test balls are tungsten carbide with a stainless-steel magnetic base and a threaded Delrin cover. Certified to 2.0 microinches (0.05 microns) accuracy, they are tested with ultra-precision measurement, NIST-traceable gage blocks, and the Donaldson ball reversal technique to isolate ball error.
Master Certification Artifact
ABTech’s large precision-ground diameter and face surfaces to easily locate gage heads and confirm system accuracy.
Universal Probe Stand with Fine Adjust Base Shown
- Vertical and Horizontal adjustment knobs
- Flexibility in arm locations
- 1/4” Ø swivel mount for LVDT’s, electronic or dial indicators (indicators not included)
- Multiple Base Configurations available
Inspection Style Gage Stands
- Heavy Duty Square post w/ Rack and Pinion
- Flexibility in arm locations
- 1/4” Ø swivel mount for LVDT’s, electronic or dial indicators (indicators not included)
- Multiple Base Configurations available
Tool Room Style Portable Gage Stands
- Basic Vertical and Horizontal arm configuration
- Flexibility in arm locations
- 1/4” Ø swivel mount for LVDT’s, electronic or dial indicators (indicators not included)
- Multiple Base Configurations available
Ultra-Fine & Fine Adjust Probe Mounts
Can be used with most gage arms and with both the lever and plunger probe mounts
- Ultra-fine adjust has a .013" pitch adjustment screw
- Fine adjust has a .020" pitch adjustment screw
MicroForm Fine Adjust
This style fine adjust typically comes on any dual-probe MicroForm system as well as some of our gage stands
- Can only be used with the lever style probe
- MicroForm fine adjust has a .020” pitch adjustment screw
Adjustable Probe Mounts (Front and Back Shown)
These adjustable probe mounts are built to be used with the dovetail found on the lever probes.
Dual Plunger-Type Gage Mounts (#08338A Shown)
Our custom probe mounts are designed to allow two probes to gain access to multiple surfaces in close proximity to each other using one horizontal arm.
Combo: Lever/Plunger-Type Gage Mount & Dual Plunger-Type Gage Mount
- The lever/plunger mount enables two probes to access a face and diameter nearby using one arm.
- The dual plunger mount allows two probes to access two ODs with a single arm.
FormCheck (Shown with Single and Dual Probe Adaptors)
This user interface displays the results in both traditional analog-style and digital formats. The maximum and minimum readings and TIR are captured, removing potential operator error and user subjectivity
Plunger Probe (Clamp Sold Separate)
Lever-Type Probes (Shown without Mounting Clamp)
ABTech offers industry standard lever-type electronic indicators.
Extension Cables
- Made to be used with both the lever and plunger-style probes.
- Various standard lengths available
- Custom lengths available on request.
90-Degree Cable Exit
- Takes a standard cable exit on a plunger probe and provide a 90° bend in the cable.
Allows for easier probe placement on parts in certain configurations.
Changeable Probe Tip Adaptor
- Uses 4-48 threaded probe tips allowing for an easy change of custom lengths, ball sizes, ball material etc.
- Eliminates left and right probe tip movement which reduces the chance of improper probe placement on part surfaces.
Custom Probe Tips
- ABTech has custom probe tips available for both lever and plunger-style probes – length, material, ball/tip size, shape
Gage Blocks for Probe Calibration
- ABTech’s precision gage blocks calibrate lever and plunger probes on standard products with electronic probes.
- Precision-ground metal blocks can be joined with minimal dimensional uncertainty.
- A few gage blocks create accurate lengths across a wide range.
Large Air Filter Regulator
- Dual filter units: small (#00787AC) with 5.0/0.5-micron filters, large (#00938AD) with 5.0/0.3-micron filters.
- Ensure performance and contaminate protection.
- Add a safety interlock sensor for powered systems.
Electronics Carts
- These electronics carts are used to mount monitors, PCs, and controllers, and provides shelf space for a keyboard, mouse, and an optional printer.
Replacement Air Filters
- We have various replacement air filters on offer for both small and large air filters and regulators.
Anti-Rotational Lock
These anti-rotational locks are made for all EAS tables. They are classified as "best practice" for torquing parts, over shutting off the air supply.
Replacement Components
- Contact ABTech for any replacement or spare parts.
Can’t find what you are looking for?
See What Our Customers are Saying
"We use 2 ABTech air-bearing spindles with tip/tilt and centering capability in our facility. These units are used for precision assembly and final metrology. We have never had an issue with either one, and the ABTech team is a great partner for us. We will be adding more systems as our young organization continues to grow".
Jayson Tierson
President, Vertex Optics
See What Our Customers are Saying
“Thanks a lot for your help [with remote technical support provided for the system installed at the South Pole]. Your rapid, informative correspondence was invaluable. Hopefully I won't be bothering you with any further questions, but it's good to know you're willing.”
Morgan Hedges
Post-Doctoral Research Associate, Princeton University
